Product Overview
Perimeter Ventilation
Increases ventilation system efficiency by pulling air from the edges of the hood and speeding up the movement of air at the center, allowing it to efficiently handle up to a 65K BTU total output.
Programmable Off Function
Can be set to automatically turn off after a period of time.
LED Task Lights
Provide extra lighting over the cooking surface to help in the cooking process.
Useful Documents
Use and Care GuideWarrantyVentilation Pairing GuideInstallation InstructionsFeature SheetDimension Guide
Specifications
General Specs |
|
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Type | Under Cabinet |
| Ventilation Type | Convertible (Both) |
| Duct Size (in.) | 6 |
| Sones Rating | 7.0 |
| Noise Level (Sones) | Standard – (High) |
| Maximum CFM | 600 |
| Range Hood Features | Automatic Shut Off |
| Fan Speed Options | 4 |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 36 |
| Height (in.) | 9 |
| Depth (in.) | 19.75 |
| Made In | Mexico |
| ENERGY STAR Certified | No |
| Voltage | 120 |
| Positioning | Stationary |
Details |
|
| Night Light | Yes |
| Number of Task Light Settings | 1 |
Ventilation System |
|
| Auto Function | Auto On |
| Blower Type | Centrifugal |
| Fliters | Dishwasher-Safe Grease Filters |
| Sound Max Speed Sones | 7.0 |
| Sound Min Speed Sones | 1-3/10 |
| Duct Direction | Vertical |
| Duct Type | Round |
| Number of Speeds | 4 |
| Sound Max Speed/Sound Max Speed DBA | 68-1/10 |
| Sound Min Speed DBA | 44-1/10 |
