Product Overview
Perimeter Ventilation
Increases ventilation system efficiency by pulling air from the edges of the hood and speeding up the movement of air at the center, allowing it to efficiently handle up to a 65K BTU total output.
Programmable Off Function
Can be set to automatically turn off after a period of time.
LED Task Lights
Provide extra lighting over the cooking surface to help in the cooking process.
600 CFM/65k BTU Threshold
Allows installation over any KitchenAid regular 36- or 30-inch range or cooktop, and some commercial-style cooking surfaces with outputs up to 65K BTU.
Whisper Quiet® System @ 44 DBA (1.3 Sones) At Low Speed
Ensures that the ventilation system operates at a quiet level so it can be used while entertaining. At maximum speed, sound level is 68 dBA (7.0 sones).
Easy In-Line Conversion
Converts from a traditional set-up to an in-line blower installation for an even more quiet operation. Metal box purchase required.
4-Speed Electronic Touch Control with Led Display
Provides sleek, visual confirmation of your ventilation selections, settings, and filter status.
Dishwasher Safe Grease Filters
Filter reduces steam, grease, and odor to help avoid contact with ceilings and countertops. The design increases filtration by obstructing the path of vented air to help capture more steam, grease, and odors as they are drawn through the vent.
Useful Documents
Use and Care GuideWarrantyVentilation Pairing GuideDimension GuideInstallation Instructions
Specifications
General Specs |
|
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Type | Under Cabinet |
| Ventilation Type | Convertible (Both) |
| Duct Size (in.) | 6 |
| Sones Rating | 7.0 |
| Noise Level (Sones) | Standard – (High) |
| Maximum CFM | 600 |
| Fan Speed Options | 4 |
| Appliance Fit Width (in.) | 30 |
| Width (in.) | 30 |
| Height (in.) | 9 |
| Depth (in.) | 19.75 |
| Made In | Mexico |
| ENERGY STAR Certified | No |
| Voltage | 120 |
| Positioning | Stationary |
Details |
|
| Night Light | Yes |
| Number of Task Light Settings | 1 |
| Task Lighting | Yes |
Ventilation System |
|
| Auto Function | Auto On |
| Duct Direction | Vertical or Horizontal |
| Number of Speeds | 4 |
| Sound Max Speed |Sound Max Speed DBA | 68 – 0.1 |
| Sound Min Speed DBA | 44 – 0.1 |
| Blower Type | Centrifugal |
| Filters | Dishwasher-Safe Grease Filters |
| Sound Max Speed Sones | 7.0 |
| Sound Min Speed Sones | 1 – 0.3 |
