Product Overview
Downdraft Ventilation
Integrates the ventilation system into the cooking surface so that a separate hood is not needed. Smoke and odors can be removed and taken outside or filtered and recirculated inside. A duct-free kit is available for purchase separately.
10” Even-Heat™ Ultra Element with Simmer Setting
Provides more versatility for high and low temperature cooking techniques. Even-Heat™ Technology maintains a constant supply of power and delivers a range of simmer settings.
6” Even-Heat™ Element with Melt Setting
Combines the benefits of Even-Heat™ Technology with a dedicated setting that reaches the low temperatures needed to melt chocolate or butter without scorching.
3-Speed Fan Control
Can be precisely matched to cooking needs, effectively removing steam, grease, and odors from the air.
Convertible to Duct-Free Ventilation
Allows a downdraft cooktop to be placed nearly anywhere in the kitchen using a duct-free conversion kit (not included). This filters and recirculates the air without running ductwork, ideal for kitchens with installation restrictions or ducting limitations.
Hot-Surface Indicator
Provides a clear indication that lets you know if any cooking surface is on or still hot.
300 CFM Exhaust Rating
Handles the venting requirements of high temperature cooking techniques like pan searing and stir-frying.
9”/6” Ultra Power™ Double-Ring Round Element
Two element sizes in one provide the ability to use it for large stock pots or six-inch sauté pans and handle tasks ranging from rapid boiling and searing to wok cooking.
Power-On Indicator Light
Lets you know at a glance when an element is on.
Pure Color Ceramic-Glass Surface
Comes in saturated colors with stainless steel control knobs for a sophisticated, easy-to-clean appearance.
Stainless Steel Knobs
Enhance the look of the cooktop surface with sturdy construction that adds to their premium feel.
6” Round Element
Can reach a power output of up to 1200 watts to handle your daily cooking needs.
Useful Documents
Owner’s ManualWarrantyVentilation Pairing ChartInstallation InstructionsDimension Guide
Specifications
General Specs |
|
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Fuel Type | Electric |
| Element Type | Radiant |
| Number of Elements/Burners | 4 |
| Cooktop Surface | Glass Top |
| Ignition Type | Automatic Electronic |
| Cooktop Features | Indicator Light – Hot Surface, Dual Element |
| Propane Convertible | No |
| Downdraft Ventilation | Yes |
| Commercial Use Approved | No |
| Appliance Fit Width (in.) | 30 |
| Width (in.) | 30.88 |
| Depth (in.) | 22.06 |
| Height (in.) | 18.75 |
| Product Weight (lbs.) | 50 |
| Cut Out Width (in.) | 28.88 |
| Cut Out Depth (in.) | 21.13 |
| ADA Compliant | No |
| ENERGY STAR Certified | Yes |
| Made In | USA |
| Manufacturer Warranty | 5 Year Limited Parts and Labor |
| Voltage | 220 |
| Frequency | 60 |
| Amp | 40 |
