Product Overview
Easy installation
10 minutes or less by one person
Two-speed, 270-CFM venting system
Removes smoke, grease, odors and moisture
Front controls
Enjoy easy access and a subtle appearance
Dual LED lighting
Choose bright light while cooking – bulbs included
Convertible venting options
Select recirculating or external venting
Vertical and rear exhaust
Exhausts from the top or rear of the hood
Appearance (Fully enclosed bottom)
Enjoy a sleek appearance from every angle
Dishwasher safe filter
Energy efficient
Filters grease and is dishwasher-safe
JVX5305 series ventilation hoods are Energy Star qualified, helping you save energy and money
Wall Switch Option
Can be converted for operation with a wall switch, offering added flexibility and ADA-compliant convenience
Useful Documents
Owner’s ManualWarrantyWall Switch InstallationUse and Care ManualQuick SpecsInstallation Instructions
Specifications
General Specs |
|
| Color | White |
| Color/Finish Name | White |
| Range Hood Type | Under Cabinet |
| Ventilation Type | Convertible (Both) |
| Vent Location | Custom |
| Duct Size (in.) | 7″ Round |
| Bulb Type | LED |
| Sones Rating | 4.5 |
| Noise Level (Sones) | Standard – (High) |
| Maximum CFM | 270 |
| Smart Compatible | No |
| Filter Indicator Light | No |
| Fan Speed Options | 2 |
| Appliance Fit Width (in.) | 30 |
| Width (in.) | 29.88 |
| Height (in.) | 5.5 |
| Depth (in.) | 20 |
| Shipping Width (in.) | 33 |
| Shipping Height (in.) | 24 |
| Product Weight (lbs.) | 20 |
| ADA Compliant | No |
| ENERGY STAR Certified | Yes |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Voltage | 120 |
| Amp | 5 |
| Positioning | Stationary |
Construction |
|
| Chimney: | Fixed |
Dimensions |
|
| Shipping Weight: | 27 |
Display |
|
| Controls: | Mechanical |
General Features |
|
| Filter Type: | Grease Filter |
| Cleanability: | Dishwasher Safe |
Other |
|
| Air Mover(s) Speed: | 2 |
| Sones (Noise Level) Rating: | 5.5 |
