Product Overview
ADA Compliant with Low-Profile Installation
Great for 34” counter top heights and raised subfloors
Autosense Cycle
A beam of light measures soil levels and water temperature to adjust to the ideal cycle time
Piranha™ hard food disposer with removable filter
To ensure consistently clean items, this stainless steel blade rotates at 3,600 RPM to pulverize food particles and helps to prevent large particles from clogging the wash arms
3-Level Wash
Expect exceptionally clean table-ready dishes with powerful wash arms
Autosense Cycle
A beam of light measures soil levels and water temperature to adjust to the ideal cycle time
Piranha™ hard food disposer with removable filter
To ensure consistently clean items, this stainless steel blade rotates to pulverize food particles and helps to prevent large particles from clogging the wash arms
Sanitize option (NSF Certified)
High-temperature rinse sanitizes and reduces by 99.999% the bacteria found on dishes
Quiet Package
dBA 47, dramatically reduces the sound of washing the dishes
Useful Documents
Owner’s ManualWarrantyUse and Care ManualQuick SpecsQuick Reference GuideEnergy GuideInstallation Instructions
Specifications
General Specs |
|
| Color | White |
| Color/Finish Name | White |
| Door Color | White |
| Handle Color | White |
| Dishwasher Type | Standard |
| Number of Cycles | 3 |
| Control Panel Type | Top |
| Tub Material | Stainless Steel |
| Door Panel Type | Solid |
| Noise level (dB) | 47 |
| Sound Rating Range | Quieter |
| Dishwasher Features | Cutlery Holder, Door/Child Lock, Food Disposal, Sensor Wash |
| Third Rack | No |
| Sanitize Option | Yes |
| Water Softener | No |
| Delay Wash (Up to hours) | 12 |
| Number Of Place Settings | 8 |
| Smart Compatible | No |
| Appliance Fit Width (in.) | 18 |
| Width (in.) | 17.75 |
| Depth (in.) | 23.5 |
| Depth Excluding Handles (in.) | 22.5 |
| Depth Including Handles (in.) | 22.5 |
| Depth w/Door Open 90 Degrees (in.) | 45.63 |
| Height (in.) | 32.5 |
| Product Weight (lbs.) | 72 |
| Cut Out Width (in.) | 18 |
| Cut Out Depth (in.) | 22.5 |
| Cut Out Height (in.) | 32.5 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| ENERGY STAR Certified | Yes |
| ADA Compliant | Yes |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 8.9 |
Features |
|
| Door Liner | Stainless Steel |
| Control Type | 4 PushbuttonsFully Integrated ElectronicTop Controls |
| Dishwasher Control Features | 3 Digit Countdown Display with 1 “Clean” light / 1 “Sanitized” light Cycle Progress IndicatorsAudible End-of-Cycle SignalCycle CountdownLast Cycle MemoryStart/Reset Pad |
| Wash System | 3-LevelStandard |
| Wash System Features | Automatic HotStartAutomatic Temperature ControlDual PumpFlood Control SystemPiranha™ Hard Food Disposer |
| Sensor | Clean Sensor |
| Wash Arms | 2 with Upper Nozzle |
| Water Filtration System | 3-Stage Manual Clean Filtration |
| Dispenser | Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | Auto SenseHeavy WashLight Wash |
| Number of Options | 5 |
| Dishwasher Options | Child LockDelay Start 1-12 Hr.Sani (NSF 184 Certified)Start/ResetTempBoost |
| Rack Features | 1 Piece Mid Silverware Basket w/ 1 Cell Cover1 Plastic Utility Shelf – UpperBall-Tipped TinesFold-Down Tines – LowerStem Safe |
| Racking System | Gray |
| Upper Rack | 1 Rack handleAdjustableNylon |
| Lower Rack | 1 Rack handleNylon |
| Dishwasher Drying Features | Condensate Dry |
| Leveling System | Leveling Legs |
| Latch | Center Pull |
| WiFi Connect | Optional (Requires part no. PBX10W00Y0) |
| Connected Capabilities | Amazon AlexaIFTTTThe Google Assistant |
| Exterior Style | 18″ Wide |
Appearance |
|
| Door Style | Full-Length Flat Door |
| Handle | Pocket Handle |
| Handle Color | Color-Matched |
| Handle Design | Recessed |
Economical/Quiet |
|
| Motor Type | Single Speed |
| Outer Wrap | U-Blanket |
| Door Insulation | InsulationMastic |
Weights and Dimensions |
|
| Cabinet Width | 18 in |
| Height w/ Legs Retracted – Minimum Height | 32 1/2 in |
| Height w/Legs Extended – Maximum Height | 34 5/8 in |
Power/Ratings |
|
| Calrod Heater Watts | 1100 |
