Product Overview
Adjustable CFM blower
High powered 610 CFM blower is downward adjustable to either 380 or 290 maximum CFM to accommodate different installation needs
Four-speed fan control
Helps draw smoke, grease, odors and moisture out of the kitchen air
LED backlit glass touch control
Attractive controls are easy to read and instantly wipe clean
Perimeter venting
Provides a clean, modern design that makes a statement of style in any kitchen.
WiFi powered by SmartHQ™
Control appliances with a smart device or just the sound of your voice
Triple LED dimmable lighting (bulbs included)
LED modules ensure bright lighting for the entire cooking environment
Duct cover included
Included duct cover reaches up to 10′ ceilings and works with optional accessories to reach up to 14′ ceilings
Convertible venting options
Choose recirculating or external venting to adapt airflow for your kitchen’s specific ventilation setup
Remote control included
Activate and adjust your hood functions from anywhere in the kitchen
Timer and clock
Enjoy the convenience of a bright display at the ideal height
Chef Connect
Automatically control the hood’s lights and fan by syncing with the range
Useful Documents
Specification SheetUser ManualWarranty
Specifications
General Specs |
|
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Trim Color | Stainless Steel |
| Range Hood Type | Wall Mounted |
| Ventilation Type | Convertible (Both) |
| Ventilation Direction | Vertical |
| Vent Location | Top |
| Grease Filter Type | Charcoal |
| Duct Size (in.) | 8 |
| Bulb Type | LED |
| Sones Rating | 1.0 – 6.0 |
| Noise Level (Sones) | Standard – (High) |
| Maximum CFM | 610 |
| Smart Compatible | Yes |
| Fan Speed Options | 4 |
| Outdoor Approved | No |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 36 |
| Height (in.) | 24 |
| Depth (in.) | 20 |
| Product Weight (lbs.) | 75 |
| ADA Compliant | Yes |
| ENERGY STAR Certified | No |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Voltage | 120 |
| Amp | 5.3 |
| Frequency | 60 |
| Positioning | Stationary |
Features |
|
| Control Location | Front |
| Control Type | Electronic Touch |
| Cooktop Lighting | 3 |
| Ducting | Vertical Only |
| Exhaust Options | RecirculatingVented to Outside |
| Fan Speed Control | 4-Speed |
| Filter Cleaning | Dishwasher Safe |
| Removable Filter | Grease & Charcoal included |
| Time Delay Shut-Off | Yes |
| CFM/ Sones Rating | 100/1.0 (Working Speed)290/2.5 (Medium Speed)380/4.0 (High Speed)610/- (Boost Speed) |
| Light Controls | On/Off/Night |
| Optional Accessories | UX12DC93SS – 12′ High Ceiling Duct Cover KitUX14DC93SS – 14′ High Ceiling Duct Cover Kit |
| WiFi Connect | Built-In |
Appearance |
|
| Blower / Light Switch Color | Backlit |
Economical/Quiet |
|
| Venting Type | Convertible |
