Product Overview
Bake Assist Temps
Bake Assist Temps offer preset temperature settings to make cooking even more convenient. Just select a temperature, press start and let the oven do the rest.
EasyAccess™ Broiler Door
The EasyAccess™ broiler door is easy to reach and can help broil large dinners like steak and roasted vegetables.
Sealed Burners
Don’t sweat the small spills. Sealed burners make cleanup easy by limiting spills from dripping beneath the cooktop.
Large Oven Capacity
5.0 cu. ft. oven capacity gives you the space you need to make dinner and dessert at the same time.
Versatile Cooktop
Our versatile cooktop features multiple burner options that provide up to 15,000 BTUs, helping you cook your favorites all at once.
Easy Touch Electronic Controls Plus
Quickly select bake or broil temperatures with these large and easy-to-read Easy Touch Electronic Controls Plus.
Temp Assure™ Cooking System
Temp Assure™ Cooking System distributes heat throughout the entire oven to deliver delicious results.
Extra-Large Oven Window
Keep an eye on your meal through the Extra-Large Oven Window.
Custom Broil
Use the Custom Broil setting to broil in five-degree increments.
Oven Lockout
Oven Lockout is a safety feature that locks your oven and its controls to help protect against accidental use.
Self-Clean Option
The Self-Clean Option uses high-temperature settings to help you clean your oven without using harsh chemicals.
Useful Documents
WarrantyQuick Start GuideControl GuideDimension GuideSpecification SheetOwner’s Manual
Specifications
General Specs |
|
| Color | Black |
| Color/Finish Name | Black |
| Door Color | Black |
| Handle Color | Black |
| Total Capacity (cu. ft.) | 5.0 |
| Number of Oven(s) | Single |
| Fuel Type | Natural Gas |
| Door Panel Type | Glass |
| Range Type | Freestanding |
| Number of Elements/Burners | 4 |
| Cooktop Surface Style | Burner Grate |
| Grate Material | Porcelain-Enameled Cast Iron |
| Oven Cleaning Method | Self Cleaning |
| Oven Features | Broiler in Oven, Hidden Bake Element, LED Display, Sabbath Mode |
| Cooktop Features | LP Convertible, Digital Display, Digital Display |
| Air Fry | No |
| Drawer Type | Storage |
| Appliance Fit Width (in.) | 30 |
| Width (in.) | 29.88 |
| Height (in.) | 46.88 |
| Depth (in.) | 27.88 |
| Depth w/Door Open 90 Degrees (in.) | 46.56 |
| Cut Out Depth (in.) | 24 |
| Cut Out Width (in.) | 30 |
| Cut Out Height (in.) | 36 |
| Product Weight (lbs.) | 187 |
| Made In The USA | Yes |
| Made In | USA |
| Manufacturer Warranty | 1 Year Parts & Labor |
| ADA Compliant | No |
Certifications |
|
| ADA Compliant | No |
Exterior Details |
|
| Door Type | Glass Window |
| Handle Material | Plastic |
| Handle Type | Reach Through Handle |
| Oven Control Location | Backguard |
| Oven Control Type | Electronic Touch |
| Oven Window Size | Extra Large |
Cooktop Details |
|
| Cooktop Control Knob Color | Color Coordinated |
| Cooktop Control Knob Type | Dishwasher Safe Plastic |
| Cooktop Control Location | Front |
| Cooktop Control Type | Knobs |
| Cooktop Surface Color | Black on Stainless |
| Cooktop Surface Material | Porcelain Coated Steel |
| Griddle Included | N/A |
| Heating Element On Indicator Light | No |
| Hot Surface Indicator Light | No |
| Ignition Type | Electronic |
Oven Cavity Details |
|
| Bake Element Power | 16,500 BTU |
| Broiler Element Power | 10,000 BTU |
| Broiler Location | Top of Oven |
| Convection Element Type | None |
| Convection Functions | No |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Interior Color | Grey |
| Number of Oven Lights | 1 |
| Oven Cleaning Type | Self-Cleaning |
| Oven Cooking System | Thermal |
| Oven Light Switch Location | Oven Control |
| Oven Light Type | Incandescent |
| Oven Rack Type | Standard |
Additional Dimensions |
|
| Depth Closed Excluding Handles | 25.44 in |
| Oven Interior Depth | 18.5 in |
| Oven Interior Height | 18.13 in |
| Oven Interior Width | 24.5 in |
Details |
|
| Fuel Type | Gas |
| LP Convertible | Yes – Kit Included |
| Oven Configuration | Single Oven |
| Oven Selections | Audible Signal, Clock, Control Lock, Sabbath Mode, Timer, Warm Hold |
| Power On Indicator Light | Yes |
| Power Outage Compatible | Yes – Cooktop Only |
| Range Configuration | Freestanding |
Element/Burner Details |
|
| Cooktop Element Style | Sealed Burner |
| Left Front Element-Burner Power | 12,500 BTU |
| Left Front Element-Burner Type | High Output |
| Left Rear Element-Burner Power | 9,500 BTU |
| Left Rear Element-Burner Type | Multi Purpose |
| Right Front Element-Burner Power | 9,500 BTU |
| Right Front Element-Burner Type | Sealed Burner |
| Right Rear Element-Burner Power | 5,000 BTU |
| Right Rear Element-Burner Type | Simmer |
Grate Details |
|
| Grate Details | Dishwasher Safe, Matte Finish, Porcelain Coated Cast Grates |
Controls |
|
| Display Color | Green |
| LED | |
Electrical |
|
| Power Cord Included | Yes |
